Features

• Dual 15-inch woofers

• Frequency range: 32 Hz–250 Hz (-10 dB)

• 136 dB maximum SPL

• Built-in DSP includes crossover management, EQ, limiting, correction filters, phase-corrected processing and driver-protection circuitry

• Integrated 1,000 watt-per-channel, 6-channel amplifier offers the most channels in its class

• Powers up to four BRX308-LA Line Array Elements

• Input: two balanced XLR-F wired in parallel to XLR-M for THRU outputs

• Output: two 4-pole NL4 connectors for powering up to four tops

• Power input: 20A powerCON/230 VAC only

• Dual inputs with Input Y mode allow a single input for the subwoofer and tops or dedicated inputs for more advanced uses

• Casters provide ease of transport

• Dimensions: 680 x 890 x 693 mm (26.7 x 35 x 27.3 inches) without caster wheels

• Weight: 86 kg (190 pounds)

• Power cable options for China, India and APAC regions
