Key Features:

• Up to 80 channels to mix

• 32 Mic Inputs

• 8 XLR/1/4" Combi-jacks for line inputs and instruments

• 40 DSP input channels (32 mono inputs and 4 stereo channels/returns)

• 31 Output busses (All with full DSP processing and GEQ)

• 4-band Fully Parametric EQ on each channel and bus

• 8 VCAs + 8 Mute groups

• 26 motorised faders (24 input + LR/Mono)

• 4 fully customisable Fader Layers

• Built-in Stagebox Connectivity

• 5" touchscreen display

• Multi-Colour LCD Channel Displays on each input fader

• 4 studio-grade Lexicon Effects engines and dedicated FX busses

• BSS Graphic Equalisers on every bus

• 20 sub-group / aux busses

• 4 mono/stereo matrix busses

• 32x32 USB audio interface for multi-track recording and playback *

• Increase I/O capabilities with option cards and stageboxes:

  • Use included MADI option card and Soundcraft Mini Stagebox 32i or 16i for more microphone preamps, inputs and channels to mix

  • Add 2nd MADI option card and two Soundcraft Mini Stagebox 32i or 16i for up to 96 microphone preamps, 136 total inputs and 80 channels to mix.

  • Add Dante option card for 64 channels of Dante to mix

  • Additional option cards available: AVIOM A-Net, CobraNet, AES/EBU, BLU Link, more

• Additional Soundcraft stageboxes available: Mini Stagebox 32R, Mini Stagebox 16R, Compact Stagebox, and Vi Stagebox

* USB Interface Compatibility: PC: Supports Windows 7, Windows 8 and Windows 10. Mac: Supports Mac OS 10.7.x Lion through 10.11.x El Capitan
